1.Describe

The High-Precision Glass Beveling Machine with Multi-Spindle System is a state-of-the-art solution for bevel grinding and polishing of flat glass. Designed with multiple precision spindles, this machine can simultaneously grind and polish, ensuring stable processing, high accuracy, and superior edge quality. It is widely used in the production of decorative glass, mirrors, furniture glass, architectural panels, and automotive glass.

2.Structure

• Loading Table: Used for automatic or manual loading, smoothly feeding glass into the processing area.

• Grinding Head Set: Includes rough grinding heads, fine grinding heads, and polishing heads, each completing different stages of the beveling process.

• Conveyor System: Uses belts to ensure smooth movement of glass.

• PLC Control System: Enables automated operation and parameter adjustment, supporting multiple processing modes.

• Cooling System: Utilizes water cooling to reduce temperature during grinding, extending the life of grinding wheels.

• Items	Description
  	Adopt SIEMENS PLC with Human interfacecontrol system, the machine can adjust automatic after input the data of glass thickness, hemline grinding and bevel width.
  	Adopts armor plate 40Cr, stable function, the low possibility of breakdown1
  	Grinding motors adopt the famous ABB brand to make the machines working precious.
  	All electric parts adopt the famous Schneider brand to drive the machine more stable and durable.
  	Coarse pitch chain in conveyor system that more durable and stable
  	Automatic cleaning equipment which can keep the rear pad cleaning. It can protect the glass surface and improve the production rate.
  	Electric device to adjust the glass thickness.
  	Electric device for adjusting the glass angle. Easy to operate.
  	With third bar functionwhich can move the motors out and in at the same time
  	Lifting systemfor adjusting to process big glass orsmall glass
  	We adopt Aluminium fluency stripsinstead of iron frame that brings the glass transmission more stable, durable for use and looks more beautiful.
  	Adopt theItaly brand Barbieri timing beltto convey the glass
  	Adopt the frequency inverterfor adjusting speed to ensure the machine working more stable while processing.
  	Adopt 2 pcs of quality stainless steel water tanks. One for water circulation size in 1400 * 500mm. The other one for cerium polishing water thank with mixer function diameter in 600 * 600mm.

3.Main technical data

4.Picture

5.FAQ

1. Can the machine handle different glass thicknesses?

Yes, most machines accommodate glass thicknesses from 3mm up to 25mm or more, depending on the model.

2. What types of glass can be beveled?

It can bevel tempered glass, laminated glass, float glass, mirror glass, and other flat glass types commonly used in windows, furniture, and decorative panels.

3. What is the typical bevel width and angle?

Most machines allow bevel widths from 1mm to 50mm, and angles can range from 0° up to 45°. depending on the machine model and tooling.

4. How does a Glass Beveling Machine work?

The machine uses diamond or abrasive grinding wheels to precisely grind and polish the edges of glass panels. Some models have automatic feeding and polishing systems for higher efficiency.
