1.Structure:
Frame: Supports the entire equipment, ensuring stability.
Grinding Head Set: Includes one rough grinding head and one fine grinding head, completing rough and fine grinding processes.
Conveyor System: Uses belts or rollers to transport glass, ensuring smooth movement.
Cooling System: Utilizes water cooling to reduce temperature during grinding, extending the life of grinding wheels.
Control System: Manual or semi-automatic control, simple operation.
2.Advantages:
Low Cost: Affordable equipment and maintenance costs, suitable for small businesses.
Easy Operation: Simple structure, easy to learn and maintain.
Strong Adaptability: Capable of processing glass of various thicknesses and sizes.
3.Specification
Model | RSY-X-09 |
Power | 1.6KW |
Overall size | 2000*1100*1050mm |
Adaptive glass thickness | 3mm-12mm |
Small platform | 1090*520*850 mm |
Minimum processing size | 300*300mm |
Maximum processing size | 1500*800mm |
4.Precautions:
Regularly check the wear of grinding wheels and replace them promptly to ensure processing quality.
Keep the cooling system clean to prevent blockages that may affect cooling efficiency.
Pay attention to safety during operation to avoid injuries caused by glass breakage.
5.Frequently Asked Questions
Q: Your machine is for rough grinding or polishing?
A: Our edging machine is for rough grinding, suitable for chamfering before the glass is tempered and insulated.
Q: Is your machine suitable for the irregular shapes make?
A: Our edging machine cannot grind the special shaped glass, because there is a row of standard wheels on the back of the platform. Our machine named TYRSY-08B is workable to the irregular shaped glass, like the triangles, waves, circles, etc.
Q: What structure does the grinding wheel of this edging machine use?
A: This edging machine uses a grinding wheel structure similar to a four-side grinding machine. It has two resin wheels or two diamond wheels. The two wheels are placed one on top of the other to form an included angle. The glass passes through the angles made by the two wheels.
Q: How long can the grinding wheels be used?
A: Based on working eight hours a day, the resin wheel can be used for more than one month, and the diamond wheel can be used for six months.
